How do nozzles work in aircraft?
What type of nozzle is used in a rocket?
- Rockets typically use a fixed convergent section followed by a fixed divergent section for the design of the nozzle. This nozzle configuration is called a convergent-divergent, or CD, nozzle. In a CD rocket nozzle, the hot exhaust leaves the combustion chamber and converges down to the minimum area, or throat, of the nozzle.
What is a CD nozzle?
- A nozzle is a relatively simple device, just a specially shaped tube through which hot gases flow. Rockets typically use a fixed convergent section followed by a fixed divergent section for the design of the nozzle. This nozzle configuration is called a convergent-divergent, or CD, nozzle.
What type of nozzle is used in a turbojet?
- Simple turbojets, and turboprops, often have a fixed geometry convergent nozzle as shown on the left of the figure. Turbofan engines often employ a co-annular nozzle as shown at the top left. The core flow exits the center nozzle while the fan flow exits the annular nozzle.
